Jiangyin Hangli Technology Co., Ltd. is one of the leading manufacturers and suppliers of industrial alligator shear in China. We offer the best custom service and OEM service for global clients. Please feel free to buy high quality industrial alligator shear at low price from our factory. Welcome to contact us for pricelist.
Alligator shear machine: an efficient scrap steel cutting equipment that empowers the metal recycling industry to reduce costs and increase efficiency.
Efficient and stable shearing equipment is the core link in improving production capacity in the recycling of waste materials and smelting and casting industries. As a professional scrap cutting equipment, the alligator shear machine (also known as the crocodile type shearing machine) is widely used in metal recycling and processing plants, scrap car dismantling yards, and small and medium-sized steel mills due to its excellent cold cutting performance. Whether it's round steel, square steel, channel steel, I-beams, steel plates, or various types of scrap metal structural components, alligator shear machines can provide powerful cutting solutions and are the main models in various metal recycling shearing machines.
Core technical parameters
Meet the requirements of multi scene cutting
Our alligator shear machine provides rich technical parameter configurations to meet the processing needs of enterprises of different scales, ensuring that the equipment can accurately match your production standards:
Shear force and blade length
The equipment's shear force covers 6 tons to 500 tons, and the working blade length covers various specifications such as 200mm to 1500mm. The 700mm and above blade models are particularly suitable for cutting and processing scrapped cars and large scrap steel, meeting the processing requirements of different material sizes.
Shear frequency and power system
Adopting advanced hydraulic transmission system, equipped with 3kW to 44kW main motor. Some high-end models are equipped with fast loop design, which can increase the cutting speed to 8-12 times per minute without increasing the motor power, significantly improving the output per unit time.
Automation level
The control system has high integration and supports three operating modes: jog, semi-automatic, and fully automatic. In fully automatic mode, the equipment can automatically complete the continuous cycle action of "pressing cutting lifting", effectively reducing manual intervention and improving the continuous operation capability of the production line.
Technical Parameters of Q43-315 Alligator Shearing Machine
|
Serial number |
Parameter content |
Remarks |
||||
|
1 |
Shear cylinder |
model |
YG280/200 |
Itinerary |
480mm |
315ons |
|
Maximum shear force |
3150kN |
quantity |
1piece |
|||
|
2 |
Pressure oil cylinder |
model |
YG140/90 |
Itinerary |
195mm |
50tons |
|
Maximum press force |
500kN |
quantity |
1piece |
|||
|
3 |
Working pressure of hydraulic system |
≤22MPa |
|
|||
|
4 |
Blade length |
1200mm |
||||
|
5 |
Maximum mouth opening |
580mm |
||||
|
6 |
Cutting range: Root position of cutting edge |
Round steel: 70mm, square steel: 60x60mm, Steel plate: 40x200mm |
Root position of the blade |
|||
|
7 |
Operation method |
Manual feeding, electronic control operation |
||||
|
8 |
Number of Cuts |
6-10 times/minute |
Empty load |
|||
|
9 |
Power Specifications |
Customized according to requirements |
||||
|
10 |
host power |
37kW |
||||
|
11 |
Fuel tank capacity |
1400L |
6 bucket |
|||
|
12 |
floor area |
6500x2800mm |
||||
|
13 |
cooler |
Model GLC-8m ² Heat exchange area 8m ² |
finned |
|||
|
14 |
motor |
model |
YE3-180L-4 |
quantity |
2 unit |
|
|
Rated speed |
1470r/min |
rated pow |
18.5kW |
|||
|
15 |
Hydraulic pump |
model |
80YCY14-1B |
quantity |
2 unit |
|
|
rated flow |
80ml/r |
rated pressure |
31.5MPa |
|||
Why Choose Hangli Technology's Industrial Alligator Shear?
Our Hydraulic Alligator Shear delivers reliable cold shearing performance for wide-range scrap metals. Featuring strong hydraulic force, durable frame, easy operation and flexible configurations, it is ideal cost-saving equipment for scrap recycling, steel processing and demolition industries, turning bulky metal waste into standardized reusable raw materials.
