Jiangyin Hangli Technology Co., Ltd. is one of the leading manufacturers and suppliers of metal bale breaker in China. We offer the best custom service and OEM service for global clients. Please feel free to buy high quality metal bale breaker at low price from our factory. Welcome to contact us for pricelist.
After Sales Service and Technical Support for Metal Dismantling Machines
Professional response: Provide comprehensive equipment operation training and daily maintenance guidance to ensure that enterprise operators can quickly get started.
Spare parts guarantee: The supply of core hydraulic components (such as wear-resistant oil seals and high-tech process oil cylinders) is stable, ensuring continuous operation of the equipment without reducing pressure.
Technical support: Provide 7 × 24-hour remote technical support and customized disassembly solutions for complex working conditions.
Suggestions for Selection of Metal Dismantling Machine
It is recommended that the purchaser clarify the following operating parameters when inquiring about metal dismantling machines, in order to obtain accurate configuration solutions:
- Types and sizes of packaging blocks to be disassembled (such as scrap steel packaging blocks, steel bar compression blocks, etc.)
- Expected disassembly processing capacity (ton/hour)
- On site power supply conditions and space limitations
- Automation level requirements (manual/PLC/remote control)
Kind reminder: Metal dismantling machines are widely used in industries such as steel, smelting, steel mills, and ports. Specific technical parameters and quotations (such as customized model prices) vary depending on the configuration. Please provide detailed operating requirements, and we will provide you with a customized technical solution that includes investment return cycle calculations.
CBJ-500 Basic Parameters of Metal Bundles Dismantling Machine
|
Serial number |
Reference nouns and content |
Note |
||||
|
1 |
Unpacking the oil cylinder |
Model |
YG500/220 |
Quantity |
1 piece |
411 tons |
|
Commonly known as pulling |
4110kN |
Journey |
1800mm |
|||
|
2 |
Clamp the cylinder |
Model |
YG260/180 |
Quantity |
4 pieces |
135 tons x 4 |
|
Public Praise for Push |
1350kNx4 |
Journey |
400mm |
|||
|
3 |
Hydraulic system operating pressure |
≤26MPa |
||||
|
4 |
Maximum travel of the unpacking head |
1800mm |
|
|||
|
5 |
Scope of unpacking (rebar bundles cannot be removed) |
Crushings pressed by the packer within 630 tons of thrust, light material briquettes, etc |
||||
|
6 |
Maximum packable block |
1800x800x800mm |
||||
|
7 |
Single no-load cycle time |
About 80 seconds |
||||
|
8 |
Operating methods |
Remote control operation |
|
|||
|
9 |
Power specifications |
380V/3P 50Hz |
||||
|
10 |
Total equipment power |
91.5kW |
||||
|
11 |
Fuel tank capacity |
3000L |
14 barrels |
|||
|
12 |
Land area |
11500x4500mm |
||||
|
13 |
Cooler |
Model |
FCE-80 |
Rated power |
1.5kW |
Air-cooled type |
|
14 |
Motors |
Model |
YE3-225M-4 |
Quantity |
2 units |
|
|
Rated speed |
1470r/min |
Rated power |
45kW |
|||
|
15 |
Hydraulic pump |
Model |
A4V250 |
Quantity |
2 units |
|
|
Nominal displacement |
250ml/r |
Rated pressure |
35MPa |
|||
Product Application
The Heavy-Duty Metal Bundle Dismantling Press is designed for steel mills, scrap metal processors, recycling companies, and metal buyers to open and inspect compressed scrap metal bundles before acceptance or payment. Scrap bundles can sometimes contain unwanted materials, foreign substances, or concealed fillers that are difficult to identify from the outside. By applying high hydraulic pressure to dismantle and separate tightly compressed bundles, the machine allows operators to examine the internal contents and verify the actual quality of delivered scrap metal.
Scrap Metal Bundle Inspection & Dismantling is particularly useful for supplier inspection and incoming scrap quality control. After dismantling the bundle, inspectors can check whether the load contains soil, cement, concrete, stones, mud, excessive moisture, or other non-metallic materials, as well as identify mixed or substituted materials that do not meet the agreed scrap specifications. This helps steel mills determine the true composition and weight of the scrap, detect potential bundle manipulation or fraudulent loading practices, and prevent unsuitable materials from entering the production process.
For steel mills purchasing large quantities of bundled scrap, the Heavy-Duty Metal Bundle Dismantling Press provides a practical solution for supplier verification, material inspection, dispute prevention, and incoming quality control. By opening selected bundles for internal inspection, purchasing and quality-control teams can make more reliable decisions based on the actual contents rather than relying solely on the external appearance or declared weight of the bundle.
