Jiangyin Hangli Technology Co., Ltd. is one of the leading manufacturers and suppliers of bale breaker in China. We offer the best custom service and OEM service for global clients. Please feel free to buy high quality bale breaker at low price from our factory. Welcome to contact us for pricelist.
Hydraulic metal dismantling machine/pressure block decomposition machine: a specialized equipment for dismantling scrap steel, scrap iron, and steel bar pressure block packages, used in scenarios such as steel plants, smelters, docks, etc., to ensure the detection of impurities in the package blocks and ensure the content of scrap steel after dismantling.
The hydraulic dismantling machine is supplied with oil through a hydraulic plunger pump, which drives the hydraulic robotic arm to grab, squeeze, and separate the package blocks. The pressure is adjustable, and some models can be dismantled in one go.
Extremely low operation and maintenance costs: The entire machine adopts hydraulic transmission, with a compact structure, no vibration, and low noise. During installation, there is no need for foot screws or complex foundations, making it extremely convenient to move and install. Low equipment failure rate, easy daily maintenance, significantly reducing operation and maintenance costs.
Flexible operation mode: supports multiple modes such as manual operation, PLC automatic control, or remote control. The integrated manual and automatic design makes operation easier, with strong stability and high safety factor.
Customization and high cost-effectiveness: Users can customize packaging specifications and sizes according to their actual needs. The Hydraulic bundle dismantling press equipment is equipped with reliable hydraulic and electrical components, and the overall performance price ratio is reasonable. It is a high-quality investment that saves manpower and reduces transportation costs.
Why Bundles Dismantling Machines Are Essential for Quality Control
Quality Inspection Enablement
The primary advantage of a bundles dismantling machine is its ability to open compressed bales for thorough inspection. Steel mills can examine incoming scrap for contaminants, non-ferrous materials, and quality consistency before feeding into furnaces . This prevents costly furnace damage and ensures steel quality.
Reduced Contamination Risk
By dismantling compressed bales, operators can identify and remove：
Non-ferrous metals (copper, aluminum, etc.)
Contaminants that affect steel quality
Materials unsuitable for specific smelting processes
Versatile Material Handling
Bundles dismantling machines handle various bundled materials including：
Scrap metal bales (steel, iron, copper, aluminum)
Technical Specifications of the CBJ-340 Metal Unpacker
|
Number |
Reference nouns and content |
Note |
||||
|
1 |
Unpacking the oil cylinder |
Model |
YG340/160 |
Quantity |
1 piece |
184 tons |
|
Commonly known as pulling |
1840kN |
Journey |
1500mm |
|||
|
2 |
Clamp the cylinder |
Model |
YG200/140 |
Quantity |
4 pieces |
75 tons x 4 |
|
Public Praise for Push |
750kNx4 |
Journey |
380mm |
|||
|
3 |
Hydraulic system operating pressure |
≤26MPa |
||||
|
4 |
Maximum travel of the unpacking head |
1500mm |
|
|||
|
5 |
Scope of unpacking (rebar bundles cannot be removed) |
Packing machine shavings and lightweight material briquettes with thrust up to 315 tons |
||||
|
6 |
Maximum packable block |
1500x700x700mm |
||||
|
7 |
Single no-load cycle time |
About 95 seconds |
||||
|
8 |
Operating methods |
Remote control operation |
|
|||
|
9 |
Power specifications |
380V/3P 50Hz |
||||
|
10 |
Total equipment power |
37.75kW |
||||
|
11 |
Fuel tank capacity |
1000L |
5 barrels |
|||
|
12 |
Land area |
10000x3500mm |
||||
|
13 |
Cooler |
Model |
FCE-35 |
Rated power |
0.75kW |
Air-cooled type |
|
14 |
Motors |
Model |
YE3-225S-4 |
Quantity |
1 unit |
|
|
Rated speed |
1470r/min |
Rated power |
37kW |
|||
|
15 |
Hydraulic pump |
Model |
A7V160 |
Quantity |
1 unit |
|
|
Nominal displacement |
160ml/r |
Rated pressure |
31.5MPa |
|||
High-Efficiency Hydraulic Bundle Dismantling Press Machine Solution
Our Hydraulic Bundle Dismantling Press Machine delivers an efficient and reliable solution for opening compressed metal bales, specially adopted by steel mills to inspect incoming scrap metal supplies. It breaks apart tightly compacted scrap bales to expose the interior materials, enabling operators to check for adulteration and fraud - such as hidden cement blocks, soil, rubble and other impurities mixed inside the metal bundles.
Engineered for heavy-duty operation in scrap yards, metal recycling plants and steel mills, this machine adopts a high-power hydraulic system to loosen and split dense compressed steel scrap bales, metal offcuts and other recyclable materials. Its heavy-duty frame and stable hydraulic pressing system ensure consistent performance during repeated bale dismantling and inspection work. By unpacking bales prior to sorting, shredding, shearing or remelting, steel mills can effectively verify scrap quality, reject non-compliant deliveries, optimize downstream recycling workflows and boost overall plant productivity.
This metal bale unpacking machine supports customisation based on bale size, material type, processing throughput, hydraulic pressure, working cycle and existing production line layout. It can work as a standalone inspection station or be integrated into a full scrap recycling production line, cutting manual labour and streamlining material handling for high-volume scrap inspection tasks. We supply bale breakers in multiple standard models: 60-ton, 120-ton, 250-ton, 315-ton and 600-ton units, to satisfy varied inspection and processing requirements of different clients.
