Jiangyin Hangli Technology Co., Ltd. is one of the leading manufacturers and suppliers of metal recycling baler in China. We offer the best custom service and OEM service for global clients. Please feel free to buy high quality metal recycling baler at low price from our factory. Welcome to contact us for pricelist.
Metal Baler Applicable Materials
Ferrous: Scrap steel, steel shavings, steel plates, rebar
Non-ferrous: Aluminum, copper, stainless steel, brass, lead, zinc
Automotive: Vehicle shells, car frames, scrap automobiles
Key Selection Criteria for Metal Baler Machine Purchasers
Characteristics of raw materials
Metal types: light waste (cans, metal plates) and heavy waste (structural steel, steel bars)
Shape and Size: The maximum initial size and thickness of the raw material
Preprocessing: Has the material been crushed or sheared? Affects packaging density
Output and efficiency requirements
Daily/hourly processing capacity: the core indicator that determines the scale of equipment
Work schedule:
Durability design for industrial-waste recycling equipment as influenced by single-shift, two-shift, and continuous-production operating regimes.
Requirements for finished product packaging
Bundle size: Must comply with downstream steel mills or transportation standards
Bundle density: High density bundles (usually>2.2 tons/cubic meter) are more expensive
Bundle weight: The ideal weight range for each bundle
Requirements for Electricity and Facilities
Power supply: Three-phase 380V standard; It can be produced according to the required voltage.
Factory conditions: Installation space, foundation load, crane capacity
Technical Parameters of Y81K-315 Metal Baler
|
Serial number |
Parameter names and contents |
Note |
||||
|
1 |
Main pressure cylinder |
Model |
YG400/280 |
Quantity |
2 pieces |
315 tons x 2 |
|
Public Praise for Push |
3150kNx2 |
Journey |
970mm |
|||
|
2 |
Side-pressing cylinder |
Model |
YG260/180 |
Quantity |
2 pieces |
270 tons |
|
Public Praise for Push |
1350kNx2 |
Journey |
2470mm |
|||
|
3 |
Door cover oil tank |
Model |
YG220/160 |
Quantity |
2 pieces |
190 tons |
|
Public Praise for Push |
950kNx2 |
Journey |
2100mm |
|||
|
4 |
Locking cylinder |
Model |
YG180/100 |
Quantity |
2 pieces |
120 tons |
|
Public Praise for Push |
600kNx2 |
Journey |
100mm |
|||
|
5 |
Hydraulic system operating pressure |
≤25MPa |
Rated at 28MPa |
|||
|
6 |
Specifications of the material box (compression chamber). |
3000x2500x1200mm |
Length x width x height |
|||
|
7 |
The cross-sectional size of the block x the shortest length |
(600x600)x600mm |
||||
|
8 |
Block density (steel) |
≤2200/m³ |
||||
|
9 |
Single no-load cycle time |
About 85 seconds |
||||
|
10 |
Operating methods |
Manual and automatic control, remote control |
||||
|
11 |
Production efficiency |
About 7-15 packs per hour |
||||
|
12 |
Methods of Dispute Resolution |
Mechanical Fault (Bag Loading) |
||||
|
13 |
Power specifications |
380V/3P 50Hz |
||||
|
14 |
Total equipment power |
93.1kW |
||||
|
15 |
Fuel tank capacity |
3000L (with patented air cooling, power 0.15kW) |
15 barrels |
|||
|
16 |
Land area |
10000x9000mm |
||||
|
17 |
Cooler |
Model |
GLC-16m² |
Heat exchange area |
16m² |
|
|
18 |
Cooling tower |
Model |
LJR-30L |
Achievements |
0.75kW |
|
|
19 |
Circulating water pump |
Model |
IRG50-125A |
Achievements |
1.1kW |
|
|
Flow |
14.5m³/h |
Speed |
2900r/min |
|||
|
20 |
Circulating oil pump |
Model |
YG40-125 |
Achievements |
1.1kW |
|
|
Flow |
8.3m³/hr |
Speed |
2900r/min |
|||
|
21 |
Motors |
Model |
YE3-225M-4 |
Quantity |
2 units |
|
|
Rated speed |
1480r/min |
Rated power |
45kW |
|||
|
22 |
Hydraulic pump |
Model |
A4V250 |
Quantity |
2 units |
|
|
Nominal displacement |
250ml/r |
Rated pressure |
35MPa |
|||
