Jiangyin Hangli Technology Co., Ltd. is one of the leading manufacturers and suppliers of metal chip briquetting machines in China. We offer the best custom service and OEM service for global clients. Please feel free to buy high quality metal chip briquetting machines at low price from our factory. Welcome to contact us for pricelist.
What is the difference between a horizontal pancake maker and a vertical pancake maker? How to choose?
The core difference between the two lies in material adaptability and equipment layout. The horizontal chip cake machine can effectively handle loose waste materials such as rolled silk and shavings through a bidirectional preloading design, solving the problem of low compression efficiency in vertical models; The Metal chip compactor equipment is low in height, easy to maintain, and convenient for horizontal docking with conveyor belts to achieve automation. The vertical chip cake machine is suitable for processing high-density chips and has a high equipment height. Suggestion: For handling loose materials such as rolled silk and shavings, or for integrating automated production lines, choose a horizontal one; If dealing with conventional chips and with ample vertical space, vertical can be chosen.
The material inside the compression chamber of a traditional vertical pancake maker is too loose during one downward movement, with very little substantial material and extremely low compression efficiency. The horizontal chip cake machine uses a feed hydraulic cylinder to perform primary pre pressing and a pre pressing hydraulic cylinder to perform secondary pre pressing. It first squeezes loose waste into tightly structured blocks in both directions, and then the main pressing cylinder presses efficiently, completely avoiding the problem of "extrusion cylinder shortage".
After forming, the density of cast iron chips can reach 5-6 tons/m ³, and the density of steel chip cakes is ≥ 4.5 tons/m ³. High density cake blocks can be directly put into the furnace for use, replacing pig iron or other metals, with a recovery loss of no more than 10% after being put into the furnace. Cast iron chips can save costs of 400-800 yuan per ton.
Okay. The horizontal chip cake machine adopts a fully enclosed design, which can separate the cutting oil from the cake during cold pressing, and the cutting oil can be recycled and reused. The compressed cake blocks are left to stand without any waste liquid dripping, which not only reduces processing costs but also meets environmental inspection requirements.
Okay. The diameter of the cake can be selected from Φ 90 to Φ 300mm, and can be customized according to customer needs
Fully automatic configuration usually includes: PLC automatic control compression cycle, spiral automatic feeder (with mixing and anti bridging), automatic discharge system, and interlock control (other feeding/discharging equipment can be linked). It can achieve multi machine operation by one person.
The horizontal pancake maker is mainly driven by a hydraulic system driven by an electric motor, and usually requires a power supply configuration. If power free operation is required, it is recommended to consult the manufacturer for diesel engine power modification plans.
Standard models usually take 40-60 days; Customized models (special cake size, voltage) require 45-90 days.
Hydraulic Briquetting Press(Horizontal Type)
|
Model |
Master cylinder pressure (ton) |
Mold cavity size (L×W×H/mm) |
Bale size (mm) |
Production (T/H) |
Main motor power (KW) |
|
Y83W-630 |
630 |
Ф180×550 |
Ф160×(160-190) |
2.5-3 |
2×45 |
|
Y83W-630 |
630 |
Ф200×550 |
Ф160×(160-200) |
3-4 |
2×45 |
|
Y83W-1250 |
1250 |
Ф300×700 |
Ф300×(240-260) |
10-12 |
2×160 |
|
Y83W-1250 |
1250 |
Ф320×700 |
Ф320×(240×260) |
12-15 |
2×160 |
